Vulkan F40/200 Effect Carbon Monoxide Cylinder Pressure Reducer DIN 477-1, 0-40 bar
Standards & Design:
according to ISO 2503, single-stage design, with pre-pressure compensation for constant outlet pressure with falling pre-pressure, with safety gauges according to DIN EN ISO 5171, with shut-off valve, max
according to DIN 477-1 No
according to EN 560, inlet gauge: 0-315/200 bar, outlet gauge: 0-60/40 bar, width x height x depth: 210 x 190 x 75 mm
Functional elements:
• shut-off valve, max
Technical data:
• outlet pressure with falling pre-pressure, with safety gauges according to DIN EN ISO 5171, with shut-off valve, max
• output: 130 Nm³/h air at 40 bar outlet pressure, inlet: 1 LH U-nut according to DIN 477-1 No
• inlet: 1 LH U-nut according to DIN 477-1 No
• outlet: G3/8 LHk x 9 mm nozzle according to EN 560, inlet gauge: 0-315/200 bar, outlet gauge: 0-60/40 bar, width x height x depth: 210 x 190 x 75 mm
Dimensions:
width x height x depth: 210 x 190 x 75 mm
Standards & Design:
according to ISO 2503, single-stage design, with pre-pressure compensation for constant outlet pressure with falling pre-pressure, with safety gauges according to DIN EN ISO 5171, with shut-off valve, max
according to DIN 477-1 No
according to EN 560, inlet gauge: 0-315/200 bar, outlet gauge: 0-60/40 bar, width x height x depth: 210 x 190 x 75 mm
Functional elements:
• shut-off valve, max
Technical data:
• outlet pressure with falling pre-pressure, with safety gauges according to DIN EN ISO 5171, with shut-off valve, max
• output: 130 Nm³/h air at 40 bar outlet pressure, inlet: 1 LH U-nut according to DIN 477-1 No
• inlet: 1 LH U-nut according to DIN 477-1 No
• outlet: G3/8 LHk x 9 mm nozzle according to EN 560, inlet gauge: 0-315/200 bar, outlet gauge: 0-60/40 bar, width x height x depth: 210 x 190 x 75 mm
Dimensions:
width x height x depth: 210 x 190 x 75 mm
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Class (purpose):
- Technical gases
Flow rate:
130 Nm³/h
Gas Quality:
up to 4.5
HP Gauge:
HP gauge scale:
0 to 315 Bar
Inlet Connection:
DIN 477-1 No. 5 (W 1 LH)
Inlet pressure:
200 Bar
LP Gauge:
LP gauge scale:
0 to 60 Bar
Material:
Brass
Outlet Connection:
G 3/8 LH x 9 mm (hose grommet)
Outlet pressure:
40 Bar
Product type:
Cylinder regulators
Regulation Type:
Single stage
Shut off valve:
Type of Gas:
Carbon monoxide (CO)
W (Width) x H (Height) x D (Depth):
210x190x75mm.
