Cylinder regulator forming gas 0-40 bar Vulkan F40/200 Effect

Cylinder pressure reducer Vulkan F40/200 Effect forming gas DIN 477-1, 0 - 40 bar according to ISO 2503, single-stage design, with pre-pressure compensation for constant back pressure with falling pre-pressure, with safety pressure gauges according to DIN EN ISO 5171, with shut-off valve, max. inlet pressure: 200 bar, outlet pressure: adjustable 0 - 40 bar, max. output: 130 Nm³/h air at 40 bar back pressure, inlet: W21.8 x 1/14 LH U-nut according to DIN 477-1 No. 1, outlet: G3/8LHk x 9 mm nozzle according to EN 560, inlet pressure gauge: 0 - 315/200 bar, outlet pressure gauge: 0 - 60/40 bar, width x height x depth: 210 x 190 x 75 mm. This cylinder pressure reducer is Available in the following versions, among others: Gas purity/membrane: Standard: - for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge): - for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard: - hose nozzle G3/8" LHk x 9mm Options (surcharge): Order number Gas purity/membrane Outlet screw connection 204383 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" LHk x 9mm 204383-815 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" LHk x 6mm 204383-814 for technical gases up to 4.5, with standard membrane External thread G3/8" LHk according to EN 560 204383-830 for technical gases up to 4.5, with standard membrane, external thread G1/2" LHk according to EN 560 204383-MM-815 for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 6mm 204383-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 9mm 204383-MM-814 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" LHk according to EN 560 204383-MM-830 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/2" LHk according to EN 560
