Type of Gas: Acetylene (C2H2), Argon (Ar), Carbon Dioxide (CO2), Carbon monoxide (CO), Compressed Air (mixture), Ethylene (C2H4), Forming gases (mixture), Helium (He), Hydrogen (H2), Methane (CH4), Nitrogen (N2), Nitrous oxide (N2O), Oxygen (O2), Propane (C3H8), Synthetic air (mixture), Tracer gases (mixture)

Regulation Type: Double stage, Single stage

Inlet pressure (max): 200, 300

Outlet pressure: 10

Gas Quality: up to 4.5 (technical gases), up to 5.0 (laboratory gases / laser gases)

Flow rate: 48

Inlet Connection: DIN 477-1 No. 10 (W 24.32 x 1/14 RH)

Outlet Connection: Compression fitting front 1/8", Compression fitting front 6 mm, Compression fitting front 8 mm, Compression fitting front 10 mm, Compression fitting front 12 mm, Compression ring fitting front 1/4", External thread G1/2" RHk according to EN 560, External thread G1/4" RHk according to EN 560, External thread G3/8" RHk according to EN 560, Hose nozzle G1/4" RHk x 6 mm, Hose nozzle G3/8" RHk x 9 mm

Material: Brass

Flowmeter: N

Blow-off valve: N

Blow-off valve: N

Type of Gas: Acetylene (C2H2), Argon (Ar), Carbon Dioxide (CO2), Ethylene (C2H4), Helium (He), Hydrogen (H2), Methane (CH4), Nitrogen (N2), Propane (C3H8), Tracer gases (mixture)

Regulation Type: Double stage

Inlet pressure (max): 200

Outlet pressure: 1,50

Gas Quality: up to 4.5 (technical gases)

Flow rate: n/a

Inlet Connection: DIN 477-1 No. 14 (M 19 x 1.5 LH)

Outlet Connection: G 3/8 LH x 9 mm (hose grommet)

Material: Brass

Flowmeter: N

Blow-off valve: N

Type of Gas: Argon (Ar), Carbon Dioxide (CO2), Forming gases (mixture)

Regulation Type: Single stage

Inlet pressure (max): 200, 300

Outlet pressure: 2,50, 4,50

Gas Quality: up to 4.5 (technical gases), up to 5.0 (laboratory gases / laser gases)

Flow rate: 0,3

Inlet Connection: DIN 477-1 No. 6 (W 21.8 x 1/14 RH)

Outlet Connection: G 1/4 RH x 6 mm (hose grommet)

Material: Brass

Flowmeter: Y

Type of Gas: Acetylene (C2H2), Argon (Ar), Carbon Dioxide (CO2), Carbon monoxide (CO), Compressed Air (mixture), Ethylene (C2H4), Forming gases (mixture), Helium (He), Hydrogen (H2), Methane (CH4), Nitrogen (N2), Nitrous oxide (N2O), Oxygen (O2), Propane (C3H8), Synthetic air (mixture), Tracer gases (mixture)

Regulation Type: Double stage, Single stage

Inlet pressure (max): 200, 300

Outlet pressure: 1,50, 4,50

Blow-off valve: N

Gas Quality: up to 4.5 (technical gases), up to 5.0 (laboratory gases / laser gases)

Flow rate: 1,92

Inlet Connection: DIN 477-1 No. 1 (W 21.80 x 1/14 LH)

Outlet Connection: G 3/8 LH x 9 mm (hose grommet)

Material: Brass

Flowmeter: Y
