Cylinder regulator helium 0-40 bar Vulkan F40/200 Effect

Cylinder pressure reducer Vulkan F40/200 Effect Helium DIN 477-1, 0 - 40 bar according to ISO 2503, single-stage design, with pre-pressure compensation for constant outlet pressure with falling pre-pressure, with safety pressure gauges according to DIN EN ISO 5171, with shut-off valve, max. inlet pressure: 200 bar, outlet pressure: adjustable 0 - 40 bar, max. output: 130 Nm?/h at 40 bar outlet pressure, inlet: W21.8 x 1/14 RH U-nut according to DIN 477-1 No. 6, outlet: G1/4 RHk x 6 mm nozzle according to EN 560, inlet pressure gauge: 0 - 315/200 bar, outlet pressure gauge: 0 - 60/40 bar, width x height x depth: 210 x 190 x 75 mm. This cylinder pressure reducer is Available in the following versions, among others: Gas purity/membrane: Standard:- for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge):- for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard:- Hose nozzle G1/4" RHk x 6mm Options (surcharge): Item numberGas purityOutlet connection 206376 for technical gases up to 4.5, with standard membrane Hose nozzle G1/4" RHk x 6mm 206376-812 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" RHk x 9mm 206376-870 for technical gases up to 4.5, with standard membrane External thread G3/8" RHk according to EN 560 206376-838 for Technical gases up to 4.5, with standard membrane, external thread G1/2" RHk according to EN 560 206376-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G1/4" RHk x 6mm 206376-MM-812 for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" RHk x 9mm 206376-MM-870 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" RHk according to EN 560 206376-MM-838 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/2" RHk according to EN 560
