Cylinder regulator methane 0-1,5 bar Vulkan F15/200 Effect

Cylinder pressure reducer Vulkan F15/200 Effect Methane DIN 477-1, 0 - 1.5 bar according to ISO 2503, with pre-pressure compensation for constant back pressure under all working conditions, single-stage design, with shut-off valve, with safety pressure gauges according to DIN EN ISO 5171, maximum inlet pressure: 200 bar, outlet pressure: 0 - 1.5 bar adjustable, maximum output: 8 Nm³/h air at 1.5 bar back pressure. Inlet: W21.8x1/14 LH U-nut according to DIN 477-1 No. 1, outlet (optional special outlet): G3/8LH x 9 mm nozzle according to EN 560, inlet pressure gauge: 0 - 315/200 bar, outlet pressure gauge: 0 - 2.5/1.5 bar, width x height x depth: 210 x 190 x 75 mm. Due to the expansion cold, The performance of the pressure reducer is severely limited and falls far short of the values ​​specified for compressed air. For increased continuous output, the use of a gas preheater may also be necessary. This cylinder pressure reducer is available in the following versions, among others: Gas purity/diaphragm: Standard: - for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge): - for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard: - G3/8 LHk x 9 mm nozzle according to EN 560 Optional (surcharge): Order number Gas purity/diaphragm Outlet screw connection 204317 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" LHk x 9mm 204317-815 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" LHk x 6mm 204317-814 for technical gases up to 4.5, with standard membrane External thread G3/8" LHk according to EN 560 204317-838 for technical gases up to 4.5, with standard membrane, external thread G1/2" LHk according to EN 560 204317-6M for technical gases up to 4.5, with standard membrane, compression fitting VA 6mm 204317-8M for technical gases up to 4.5, with standard membrane, compression fitting VA 8mm 204317-10M for technical gases up to 4.5, with standard membrane, compression fitting VA 10mm 204317-12M for technical gases up to 4.5, with standard membrane, compression fitting VA 12mm 204317-2 for technical gases up to 4.5, with standard membrane, compression fitting VA 1/8" 204317-4 for technical gases up to 4.5, with standard membrane Compression fitting VA 1/4" 204317-MM-815 for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 6mm 204317-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 9mm 204317-MM-870 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" LHk according to EN 560 204317-MM-838 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/2" LHk according to EN 560 204317-MM-6M ​​for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 6mm 204317-MM-8M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 8mm 204317-MM-10M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 10mm 204317-MM-12M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 12mm 204317-MM-2 for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 1/8" 204317-MM-4 for pure gases up to 5.0, with Metal membrane SS321 (1.4541) compression fitting VA 1/4"
