Cylinder regulator nitrous oxide (N2O) 0-1,5 bar Vulkan F15/2 100 Effect

Vulkan
Write a review
Ask a question
202250
+ −
Buy now with 1-click

Vulkan F15/2 100 nitrous oxide N2O cylinder pressure reducer DIN 477-1, 0 - 1.5 bar
Standards & Design:

according to DIN EN ISO 2503, Class 0, two-stage design, with safety pressure gauges according to DIN EN ISO 5171, with shut-off valve
according to DIN 477-1 No
according to EN 560

Functional elements:

• shut-off valve

Technical data:

• Maximum inlet pressure: 100 bar
• outlet pressure
• Output pressure: 0 - 1
• Inlet: G3/8RH U-nut according to DIN 477-1 No
• Outlet: G 1/4 RHk x 6mm nozzle according to EN 560
• Inlet pressure gauge: 0 - 160/100 bar
• Outlet pressure gauge: 0 - 2

Dimensions:

Width x Height x Depth: 240 x 190 x 75 mm

Type of Gas:
Nitrous oxide (N2O)
Product type:
Cylinder regulators
Regulation Type:
Double stage
Inlet pressure (max):
100 Bar
Outlet pressure:
0 - 1,5 Bar
Gas Quality:
up to 4.5 (technical gases)
Flow rate:
8 Nm³/h
Inlet Connection:
DIN 477-1 No. 11 (G 3/8 RH)
Outlet Connection:
G 1/4 RH x 6 mm (hose grommet)
Application:
  • Automotive Industry
  • Chemical Industry
  • Cutting
  • Manufacturing Industry
  • Petrochemical Industry
  • Pharmaceutical Industry
  • Research & Development
  • Welding
Class (purpose):
  • Technical gases
Material:
Brass
HP gauge scale:
0 to 160 Bar
LP gauge scale:
0 to 2,5 Bar
W (Width) x H (Height) x D (Depth):
240x190x75mm.
