Cylinder regulator oxygen 0-40 bar Vulkan F40/300 Effect

Vulkan F40/300 Effect Oxygen cylinder pressure reducer DIN 477-5, 0 - 40 bar according to ISO 2503, with pre-pressure compensation for constant back pressure under all working conditions. Single-stage design, with safety pressure gauges according to DIN EN ISO 5171, with shut-off valve and metal diaphragm. Maximum inlet pressure: 300 bar. Output pressure: 0 - 40 bar adjustable. Maximum output: 120 Nm³/h compressed air at 40 bar back pressure. Inlet: W30x2RH U-nut according to DIN 477-5 No. 59. Outlet: G1/4RHk x 6 mm nozzle according to EN 560. Inlet pressure gauge: 0 - 400/300 bar. Outlet pressure gauge: 0 - 60/40 bar. Width x Height x Depth: 210 x 210 x 75 mm. Important note for 300 bar pressure reducers - Please Check your cylinder connection! Cylinder pressure regulators for 300 bar have a manual connection according to DIN 477 Part 5 and are NOT backward compatible. This means they do NOT fit cylinders with a maximum filling pressure of 200 bar! If necessary, see our following tutorial, 3: Difference between 200 bar and 300 bar pressure regulators. This cylinder pressure reducer is available in the following versions, among others: Gas purity/diaphragm: Standard: - for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge): - for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard: - hose nozzle G1/4" RHk x 6mm Options (surcharge): Item number Gas purity Outlet connection 318350 for technical gases up to 4.5, with standard membrane Hose nozzle G1/4" RHk x 6mm 318350-812 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" RHk x 9mm 318350-870 for technical gases up to 4.5, with standard membrane External thread G3/8" RHk according to EN 560 318350-838 for technical gases up to 4.5, with standard membrane, external thread G1/2" RHk according to EN 560 318350-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G1/4" RHk x 6mm 318350-MM-812 for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" RHk x 9mm 318350-MM-870 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" RHk according to EN 560 318350-MM-838 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/2" RHk according to EN 560
