Vulkan F10/20 Propane cylinder pressure reducer DIN 477-1, 0-4 bar
Standards & Design:
single-stage design, according to ISO 2503, with shut-off valve, with safety pressure gauges according to DIN EN ISO 5171, maximum inlet pressure: 20 bar, adjustable outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
according to DIN 477-1 No
according to EN 560, input pressure gauge: 0-40/20 bar, output pressure gauge: 0-6/4 bar, width x height x depth: 210 x 190 x 75 mm
Functional elements:
• shut-off valve, with safety pressure gauges according to DIN EN ISO 5171, maximum inlet pressure: 20 bar, adjustable outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
Technical data:
• maximum inlet pressure: 20 bar, adjustable outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
• outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
• output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
Dimensions:
width x height x depth: 210 x 190 x 75 mm
Standards & Design:
single-stage design, according to ISO 2503, with shut-off valve, with safety pressure gauges according to DIN EN ISO 5171, maximum inlet pressure: 20 bar, adjustable outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
according to DIN 477-1 No
according to EN 560, input pressure gauge: 0-40/20 bar, output pressure gauge: 0-6/4 bar, width x height x depth: 210 x 190 x 75 mm
Functional elements:
• shut-off valve, with safety pressure gauges according to DIN EN ISO 5171, maximum inlet pressure: 20 bar, adjustable outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
Technical data:
• maximum inlet pressure: 20 bar, adjustable outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
• outlet pressure: 0-4 bar, maximum output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
• output: 10 kg/h propane at 4 bar outlet pressure, input: propane combination connection, W21
Dimensions:
width x height x depth: 210 x 190 x 75 mm
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Class (purpose):
- Technical gases
Gas Quality:
up to 4.5
HP Gauge:
HP gauge scale:
0 to 40 Bar
Inlet Connection:
DIN 477-1 No. 1 (W 21.80 x 1/14 LH)
Inlet pressure:
8 Bar
LP Gauge:
LP gauge scale:
0 to 6 Bar
Material:
Brass
Outlet Connection:
G 3/8 LH x 9 mm (hose grommet)
Outlet pressure:
4 Bar
Product type:
Cylinder regulators
Regulation Type:
Single stage
Shut off valve:
Type of Gas:
Propane (C3H8)
W (Width) x H (Height) x D (Depth):
210x190x75mm.
