Cylinder regulator SF6 (sulfur hexafluoride) 0-1,5 bar Vulkan F15/40 Effect

Vulkan
Write a review
Ask a question
20631502
+ −
Buy now with 1-click

Vulkan F15/40 Effect SF6 (sulfur hexafluoride) cylinder pressure reducer DIN 477-1, 0-1.5 bar
Standards & Design:

according to ISO 2503, with pre-pressure compensation for constant outlet pressure under all operating conditions, single-stage design, with shut-off valve, with safety gauges according to ISO 5171
according to DIN 477-1
according to EN 560

Functional elements:

• shut-off valve, with safety gauges according to ISO 5171

Technical data:

• Maximum inlet pressure: 40 bar
• outlet pressure under all operating conditions, single-stage design, with shut-off valve, with safety gauges according to ISO 5171
• Output pressure: 0-1
• Inlet: W 21
• Outlet: G 1/4 RHk x 6 mm nozzle according to EN 560

Dimensions:

Width x Height x Depth: 210 x 190 x 75 mm

Type of Gas:
Sulfur hexafluoride (SF6)
Product type:
Cylinder regulators
Regulation Type:
Single stage
Inlet pressure (max):
40 Bar
Outlet pressure:
0 - 1,5 Bar
Gas Quality:
up to 4.5 (technical gases)
Flow rate:
8 Nm³/h
Inlet Connection:
DIN 477-1 No. 6 (W 21.8 x 1/14 RH
Outlet Connection:
G 1/4 RH x 6 mm (hose grommet)
Application:
  • Automotive Industry
  • Chemical Industry
  • Cutting
  • Manufacturing Industry
  • Petrochemical Industry
  • Pharmaceutical Industry
  • Research & Development
  • Welding
Class (purpose):
  • Technical gases
Material:
Brass
HP gauge scale:
0 to 60 Bar
LP gauge scale:
0 to 2,5 Bar
W (Width) x H (Height) x D (Depth):
210x190x75mm.
