Vulkan F20/40 Effect SF6 (sulfur hexafluoride) cylinder pressure reducer DIN 477, 0-20 bar
Standards & Design:
according to ISO 2503, Class 3, with pre-pressure compensation for constant outlet pressure under all operating conditions, single-stage design, with shut-off valve, with safety gauges according to ISO 5171, maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
according to DIN 477-1, Outlet: G 1/4 RHk x 6 mm nozzle according to EN 560, inlet gauge: 0-60/40 bar, outlet gauge: 0-40/20 bar, width x height x depth: 210 x 190 x 75 mm
Functional elements:
• shut-off valve, with safety gauges according to ISO 5171, maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
Technical data:
• maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
• outlet pressure under all operating conditions, single-stage design, with shut-off valve, with safety gauges according to ISO 5171, maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
• output: 75 Nm³/h compressed air at 20 bar outlet pressure
• Inlet: W 21
• Outlet: G 1/4 RHk x 6 mm nozzle according to EN 560, inlet gauge: 0-60/40 bar, outlet gauge: 0-40/20 bar, width x height x depth: 210 x 190 x 75 mm
Dimensions:
width x height x depth: 210 x 190 x 75 mm
Standards & Design:
according to ISO 2503, Class 3, with pre-pressure compensation for constant outlet pressure under all operating conditions, single-stage design, with shut-off valve, with safety gauges according to ISO 5171, maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
according to DIN 477-1, Outlet: G 1/4 RHk x 6 mm nozzle according to EN 560, inlet gauge: 0-60/40 bar, outlet gauge: 0-40/20 bar, width x height x depth: 210 x 190 x 75 mm
Functional elements:
• shut-off valve, with safety gauges according to ISO 5171, maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
Technical data:
• maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
• outlet pressure under all operating conditions, single-stage design, with shut-off valve, with safety gauges according to ISO 5171, maximum inlet pressure: 40 bar, outlet pressure: 0-20 bar, adjustable, maximum output: 75 Nm³/h compressed air at 20 bar outlet pressure
• output: 75 Nm³/h compressed air at 20 bar outlet pressure
• Inlet: W 21
• Outlet: G 1/4 RHk x 6 mm nozzle according to EN 560, inlet gauge: 0-60/40 bar, outlet gauge: 0-40/20 bar, width x height x depth: 210 x 190 x 75 mm
Dimensions:
width x height x depth: 210 x 190 x 75 mm
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Class (purpose):
- Technical gases
Flow rate:
75 Nm³/h
Gas Quality:
up to 4.5
HP Gauge:
HP gauge scale:
0 to 60 Bar
Inlet Connection:
DIN 477-1 No. 6 (W 21.8 x 1/14 RH
Inlet pressure:
40 Bar
LP Gauge:
LP gauge scale:
0 to 40 Bar
Material:
Brass
Outlet Connection:
G 1/4 RH x 6 mm (hose grommet)
Outlet pressure:
20 Bar
Product type:
Cylinder regulators
Regulation Type:
Single stage
Shut off valve:
Type of Gas:
Sulfur hexafluoride (SF6)
W (Width) x H (Height) x D (Depth):
210x190x75mm.
