Vulkan F20/200 Effect synthetic air cylinder pressure reducer, DIN 477-1, 0-20 bar, with pre-pressure compensation for constant
Standards & Design:
Single-stage design, with shut-off valve, with safety gauges according to DIN ISO 5171
according to DIN 477-1 No
according to DIN EN 560
Functional elements:
• shut-off valve, with safety gauges according to DIN ISO 5171
Technical data:
• Maximum inlet pressure: 200 bar
• outlet pressure under all operating conditions
• Output pressure: 0-20 bar adjustable
• Inlet: G 3/4 RH U-nut according to DIN 477-1 No
• Outlet: G 1/4 RHk x 6mm nozzle according to DIN EN 560
Dimensions:
Width x Height x Depth: 210 x 210 x 75 mm
Standards & Design:
Single-stage design, with shut-off valve, with safety gauges according to DIN ISO 5171
according to DIN 477-1 No
according to DIN EN 560
Functional elements:
• shut-off valve, with safety gauges according to DIN ISO 5171
Technical data:
• Maximum inlet pressure: 200 bar
• outlet pressure under all operating conditions
• Output pressure: 0-20 bar adjustable
• Inlet: G 3/4 RH U-nut according to DIN 477-1 No
• Outlet: G 1/4 RHk x 6mm nozzle according to DIN EN 560
Dimensions:
Width x Height x Depth: 210 x 210 x 75 mm
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Flow rate:
75 Nm³/h
HP Gauge:
HP gauge scale:
0 to 315 Bar
Inlet pressure:
200 Bar
LP gauge scale:
0 to 40 Bar
Material:
Brass
Outlet pressure:
20 Bar
Product type:
Cylinder regulators
Regulation Type:
Single stage
Shut off valve:
Type of Gas:
Synthetic air (mixture)
W (Width) x H (Height) x D (Depth):
210x210x75mm.
