Vulkan F15/200 Effect LabLine nitrogen cylinder pressure reducer 0-1.5 bar, fully chrome-plated with a metal diaphragm for gas purity 5.0, with pre-pressure compensation for constant back pressure under all operating conditions
Standards & Design:
single-stage design, with shut-off valve, with safety gauges according to DIN EN ISO 5171, maximum inlet pressure: 200 bar, adjustable outlet pressure: 0-1
according to DIN 477-1 No
Functional elements:
• shut-off valve, with safety gauges according to DIN EN ISO 5171, maximum inlet pressure: 200 bar, adjustable outlet pressure: 0-1
Technical data:
• maximum inlet pressure: 200 bar, adjustable outlet pressure: 0-1
• outlet pressure: 0-1
• output: 8 Nm³/h compressed air at 1
• Inlet: W24
• outlet: 6 mm stainless steel compression fitting
Dimensions:
Width x Height x Depth: 210 x 190 x 75 mm
Standards & Design:
single-stage design, with shut-off valve, with safety gauges according to DIN EN ISO 5171, maximum inlet pressure: 200 bar, adjustable outlet pressure: 0-1
according to DIN 477-1 No
Functional elements:
• shut-off valve, with safety gauges according to DIN EN ISO 5171, maximum inlet pressure: 200 bar, adjustable outlet pressure: 0-1
Technical data:
• maximum inlet pressure: 200 bar, adjustable outlet pressure: 0-1
• outlet pressure: 0-1
• output: 8 Nm³/h compressed air at 1
• Inlet: W24
• outlet: 6 mm stainless steel compression fitting
Dimensions:
Width x Height x Depth: 210 x 190 x 75 mm
Type of Gas:
Carbon Dioxide (CO2)
Product type:
Cylinder regulators
Regulation Type:
Double stage
Inlet pressure (max):
200 Bar
Outlet pressure:
0 - 0,25 Bar
Gas Quality:
up to 4.5 (technical gases)
Flow rate:
n/a Nm³/h
Inlet Connection:
DIN 477-1 No. 6 (W 21.8 x 1/14 RH)
Outlet Connection:
G 1/4 RH x 6 mm (hose grommet)
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Class (purpose):
- Technical gases
Material:
Brass
Relief valve:
N
Shut off valve:
N
Flowmeter:
N
HP Gauge:
HP gauge scale:
0 to 315 Bar
LP Gauge:
LP gauge scale:
0 to 0,250 Bar
Blow-off valve:
N
W (Width) x H (Height) x D (Depth):
150x210x120mm.
