Cylinder regulator test gas 0-40 bar Vulkan F40/200 Effect

Vulkan F40/200 Effect test gas cylinder pressure reducer DIN 477-1, 0-40 bar, with pre-pressure compensation for constant outlet pressure under all operating conditions. Single-stage design, with safety pressure gauges according to DIN EN ISO 5171, with shut-off valve. Maximum inlet pressure: 200 bar. Output pressure: 0-40 bar adjustable. Maximum output: 120 Nm³/h air at 40 bar outlet pressure. Inlet: M19x1.5LH U-nut according to DIN 477-1 No. 14. Outlet: G3/8LHk x 9 mm nozzle according to EN 560. Inlet pressure gauge: 0-315/200 bar. Outlet pressure gauge: 0-60/40 bar. Width x Height x Depth: 210 x 210 x 75 mm. This cylinder pressure reducer is available in the following versions, among others: Gas purity/membrane: Standard:- for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge):- for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard:- hose nozzle G3/8" LHk x 9mm Options (surcharge): Order numberGas purity/membraneOutlet screw connection 203383 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" LHk x 9mm 203383-815 for technical gases up to 4.5, with standard membrane Hose nozzle G3/8" LHk x 6mm 203383-814 for technical gases up to 4.5, with standard membrane External thread G3/8" LHk according to EN 560 203383-830 for technical gases up to 4.5, with standard membrane, external thread G1/2" LHk according to EN 560 203383-MM-815 for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 6mm 203383-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 9mm 203383-MM-814 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" LHk according to EN 560 203383-MM-830 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/2" LHk according to EN 560
