Cylinder regulator with flowmeter hydrogen 2-30 Nl/min Vulkan F10/200F Effect

Bottle pressure reducer Vulkan F10/200 F Effect Flowmeter hydrogen 2-30 Nl/min according to ISO 2503, class 20, single-stage design with flowmeter for monitoring the exact flow rate in Nl/min, TUV type-tested in accordance with Pressure Equipment Directive 97/23/EC with pre-pressure compensation for constant back pressure with falling pre-pressure, with safety pressure gauges according to ISO 5171, with shut-off valve. Inlet pressure max: 200 bar. Outlet pressure: 4.5 bar, fixed setting. Output: 2 - 30 Nl/min. Hydrogen adjustableInlet: W21.8x1/14LH U-nut according to DIN 477-1,Outlet (optional special outlet): G 3/8LHk x 9mm nozzle according to DIN EN 560Inlet pressure gauge: 0 - 315 / 200 barWidth x Height x Depth: 210 x 230 x 75 mm This cylinder pressure reducer is available in the following versions: Gas purity/diaphragm: Standard:- for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge):- for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard:- G3/8 LHk x 9 mm nozzle according to EN 560 Optional (surcharge): Order numberGas purity/diaphragmOutlet screw connection 224706 for technical Gases up to 4.5, with standard membrane hose nozzle G3/8" LHk x 9mm 224706-815 for technical gases up to 4.5, with standard membrane hose nozzle G3/8" LHk x 6mm 224706-814 for technical gases up to 4.5, with standard membrane external thread G3/8" LHk according to EN 560 224706-838 for technical gases up to 4.5, with standard membrane external thread G1/2" LHk according to EN 560 224706-6M for technical gases up to 4.5, with standard membrane compression fitting VA 6mm 224706-8M for technical gases up to 4.5, with standard membrane compression fitting VA 8mm 224706-10M for technical gases up to 4.5, with standard membrane compression fitting VA 10mm 224706-12M for technical gases up to 4.5, with standard membrane compression fitting made of stainless steel 12mm 224706-2 for technical gases up to 4.5, with standard membrane compression fitting made of stainless steel 1/8" 224706-4 for technical gases up to 4.5, with standard membrane compression fitting made of stainless steel 1/4" 224706-MM-815 for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 6mm 224706-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) hose nozzle G3/8" LHk x 9mm 224706-MM-814 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" LHk according to EN 560 224706-MM-838 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/2" LHk according to EN 560 224706-MM-6M ​​for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 6mm 224706-MM-8M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 8mm 224706-MM-10M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 10mm 224706-MM-12M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 12mm 224706-MM-2 for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 1/8" 224706-MM-4 for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 1/4"
