Vulkan L15 line pressure reducer for inert gases G1/2RH, 0 - 1.5 bar
Standards & Design:
single-stage design, with safety pressure gauges according to DIN ISO 5171, maximum inlet pressure: 20 bar, outlet pressure: 0 to 1
according to EN 560, output: external thread G1/2RH according to EN 560, input pressure gauge: 0 to 40/20 bar, output pressure gauge: 0 to 2
Technical data:
• maximum inlet pressure: 20 bar, outlet pressure: 0 to 1
• outlet pressure: 0 to 1
• output: 8 Nm³/h compressed air at 1
Dimensions:
width x height x depth: 200 x 200 x 75 mm
Standards & Design:
single-stage design, with safety pressure gauges according to DIN ISO 5171, maximum inlet pressure: 20 bar, outlet pressure: 0 to 1
according to EN 560, output: external thread G1/2RH according to EN 560, input pressure gauge: 0 to 40/20 bar, output pressure gauge: 0 to 2
Technical data:
• maximum inlet pressure: 20 bar, outlet pressure: 0 to 1
• outlet pressure: 0 to 1
• output: 8 Nm³/h compressed air at 1
Dimensions:
width x height x depth: 200 x 200 x 75 mm
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Class (purpose):
- Technical gases
Flow rate:
8 Nm³/h
Gas Quality:
up to 4.5
HP Gauge:
HP gauge scale:
0 to 40 Bar
Inlet Connection:
G 1/2 RHak (according to EN 560)
Inlet pressure:
20 Bar
LP Gauge:
LP gauge scale:
0 to 2,5 Bar
Material:
Brass
Outlet Connection:
G 1/2 RHak (according to EN 560)
Outlet pressure:
1,5 Bar
Product type:
Line Pressure Regulators
Regulation Type:
Single stage
Type of Gas:
Carbon Dioxide (CO2)
W (Width) x H (Height) x D (Depth):
200x200x75mm.
