Vulkan LR40 nitrogen ribbed line pressure reducer G3/4RHak, 15-40 bar
Standards & Design:

single-stage design, with safety pressure gauges according to DIN EN ISO 5171, maximum inlet pressure: 100 bar, output pressure: 15-40 bar, adjustable, maximum output: 280 Nm³/h compressed air at 40 bar outlet pressure and 81 bar inlet pressure, input: external thread G3/4RHak, output: external thread G3/4RHak, input pressure gauge: 0-160/100 bar, output pressure gauge: 0-60/40 bar, width x height x depth: 215 x 330 x 85 mm

Technical data:

• maximum inlet pressure: 100 bar, output pressure: 15-40 bar, adjustable, maximum output: 280 Nm³/h compressed air at 40 bar outlet pressure and 81 bar inlet pressure, input: external thread G3/4RHak, output: external thread G3/4RHak, input pressure gauge: 0-160/100 bar, output pressure gauge: 0-60/40 bar, width x height x depth: 215 x 330 x 85 mm
• outlet pressure and 81 bar inlet pressure, input: external thread G3/4RHak, output: external thread G3/4RHak, input pressure gauge: 0-160/100 bar, output pressure gauge: 0-60/40 bar, width x height x depth: 215 x 330 x 85 mm
• output pressure: 15-40 bar, adjustable, maximum output: 280 Nm³/h compressed air at 40 bar outlet pressure and 81 bar inlet pressure, input: external thread G3/4RHak, output: external thread G3/4RHak, input pressure gauge: 0-160/100 bar, output pressure gauge: 0-60/40 bar, width x height x depth: 215 x 330 x 85 mm

Dimensions:

width x height x depth: 215 x 330 x 85 mm
