Vulkan LR60 nitrogen ribbed pressure reducer G3/4RH, external on both sides
Standards & Design:
Single-stage design, with safety pressure gauges according to DIN EN ISO 5171
Technical data:
• Maximum inlet pressure: 100 bar
• outlet pressure
• Output pressure: 15 - 60 bar adjustable
• Inlet: external thread G3/4RHak, Outlet: external thread G3/4RHak
• Outlet: external thread G3/4RHak
• Inlet pressure gauge: 0 - 160/100 bar
• Outlet pressure gauge: 0 - 100/60 bar
Dimensions:
Width x Height x Depth: 215 x 330 x 85 mm
Standards & Design:
Single-stage design, with safety pressure gauges according to DIN EN ISO 5171
Technical data:
• Maximum inlet pressure: 100 bar
• outlet pressure
• Output pressure: 15 - 60 bar adjustable
• Inlet: external thread G3/4RHak, Outlet: external thread G3/4RHak
• Outlet: external thread G3/4RHak
• Inlet pressure gauge: 0 - 160/100 bar
• Outlet pressure gauge: 0 - 100/60 bar
Dimensions:
Width x Height x Depth: 215 x 330 x 85 mm
Type of Gas:
Hydrogen (H2)
Product type:
Line Pressure Regulators
Regulation Type:
Single stage
Inlet pressure (max):
100 Bar
Outlet pressure:
0 - 25 Bar
Gas Quality:
up to 4.5 (technical gases)
Flow rate:
370 Nm³/h
Inlet Connection:
G 3/4 RHak (according to EN 560)
Outlet Connection:
G 3/4 RHak (according to EN 560)
Application:
- Automotive Industry
- Chemical Industry
- Cutting
- Manufacturing Industry
- Petrochemical Industry
- Pharmaceutical Industry
- Research & Development
- Welding
Class (purpose):
- Technical gases
Material:
Brass
HP Gauge:
HP gauge scale:
0 to 160 Bar
LP Gauge:
LP gauge scale:
0 to 100 Bar
W (Width) x H (Height) x D (Depth):
215x330x85mm.
