Main regulator Helium 0-20 bar Vulkan H20/300 Effect

Main pressure reducer Vulkan H20/300 Effect Helium DIN 477-5, 0 - 20 bar according to DIN EN ISO 7291, single-stage design, with pre-pressure compensation for constant back pressure with falling pre-pressure, with safety pressure gauges according to DIN EN ISO 5171. Maximum inlet pressure: 300 bar. Output pressure: 0 - 20 bar adjustable. Maximum output: 75 Nm³/h air at 20 bar back pressure. Inlet: W30x2RH U-nut according to DIN 477-5. Outlet connection: G1/2RHak according to DIN EN 560. Inlet pressure gauge: 0 - 400 / 300 bar. Outlet pressure gauge: 0 - 40/20 bar. Width x height x depth: 200 x 190 x 75 mm. Important note for 300 bar pressure reducers - please check your cylinder connection! Cylinder pressure regulators for 300 bar have a manual connection according to DIN 477 Part 5 and are NOT backward compatible. This means they do NOT fit cylinders with a maximum filling pressure of 200 bar! If necessary, see our following tutorial, 3: Difference between 200 bar and 300 bar pressure regulators. This main pressure reducer is available in the following versions, among others: Gas purity/diaphragm: Standard: - for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge): - for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard: - G1/2RHak according to EN 560 Options (surcharge): Item number Gas purity Outlet connection 30652026 for technical gases up to 4.5, with standard membrane G1/2RHak according to EN 560 30652026-800 for technical gases up to 4.5, with standard membrane External thread G1/4" RHk according to EN560 30652026-870 for technical gases up to 4.5, with standard membrane External thread G3/8" RHk according to EN 560 30652026-6M for technical gases up to 4.5, with standard membrane, compression fitting VA 6mm 30652026-8M for technical gases up to 4.5, with standard membrane, compression fitting VA 8mm 30652026-10M for technical gases up to 4.5, with standard membrane, compression fitting VA 10mm 30652026-12M for technical gases up to 4.5, with standard membrane, compression fitting VA 12mm 30652026-15M for technical gases up to 4.5, with standard membrane, compression fitting VA 15mm 30652026-18M for technical gases up to 4.5, with standard membrane, compression fitting VA 18mm 30652026-MM for pure gases up to 5.0, with metal membrane SS321 (1.4541) G1/2RHak according to EN 560 30652026-MM-800 for pure gases up to 5.0, with metal diaphragm SS321 (1.4541) external thread G1/4" RHk according to EN560 30652026-MM-870 for pure gases up to 5.0, with metal diaphragm SS321 (1.4541) external thread G3/8" RHk according to EN 560 30652026-MM-6M ​​for pure gases up to 5.0, with metal diaphragm SS321 (1.4541) compression fitting VA 6mm 30652026-MM-8M for pure gases up to 5.0, with metal diaphragm SS321 (1.4541) compression fitting VA 8mm 30652026-MM-10M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 10mm 30652026-MM-12M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 12mm 30652026-MM-15M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 15mm 30652026-MM-18M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 18mm
