Main regulator Hydrogen 0-20 bar Vulkan H20/300 Effect

Main pressure reducer Vulkan H20/300 Effect fuel gases DIN 477-5, 0-20 bar, 75 Nm?/h according to ISO 7291, single-stage design, with pre-pressure compensation for constant back pressure with falling pre-pressure, with safety gauges according to DIN EN ISO 5171. Maximum inlet pressure: 300 bar. Output pressure: 0 - 20 bar adjustable. Maximum output: 75 Nm?/h at 20 bar back pressure. Inlet: W30x2LH U-nut according to DIN 477-5. Outlet: G1/2RHak according to EN 560. Blow-off line connection: G1/4RHak. Inlet pressure gauge: 0 - 400/300 bar. Outlet pressure gauge: 0 - 40/20 bar. Width x Height x Depth: 200 x 190 x 75 mm. Important note for 300 bar pressure reducers - Please check your cylinder connection! Cylinder pressure regulators for 300 bar have a manual connection according to DIN 477 Part 5 and are NOT backward compatible. This means they do NOT fit cylinders with a maximum filling pressure of 200 bar! If necessary, see our following tutorial, 3: Difference between 200 bar and 300 bar pressure regulators. This main pressure reducer is available in the following versions, among others: Gas purity/diaphragm: Standard: - for technical gases up to a gas purity of 4.5 with standard membrane Optional (surcharge): - for pure gases up to a gas purity of 5.0 with stainless steel membrane SS321 (1.4541) Special outlet screw connection: Standard: - G1/2RHak according to EN 560 Options (surcharge): Item number Gas purity Outlet connection 304520 for technical gases up to 4.5, with standard membrane G1/2RHak according to EN 560 304520-800 for technical gases up to 4.5, with standard membrane external thread G1/4" RHk according to EN560 304520-870 for technical gases up to 4.5, with standard membrane external thread G3/8" RHk according to EN 560 304520-6M for technical gases up to 4.5, with standard membrane, compression fitting made of stainless steel 6mm 304520-8M for technical gases up to 4.5, with standard membrane, compression fitting made of stainless steel 8mm 304520-10M for technical gases up to 4.5, with standard membrane, compression fitting made of stainless steel 10mm 304520-12M for technical gases up to 4.5, with standard membrane, compression fitting made of stainless steel 12mm 304520-15M for technical gases up to 4.5, with standard membrane, compression fitting made of stainless steel 15mm 304520-18M for technical gases up to 4.5, with standard membrane, compression fitting made of stainless steel 18mm 304520-MM for pure gases up to 5.0, with metal membrane made of SS321 (1.4541) G1/2RHak according to EN 560 304520-MM-800 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G1/4" RHk according to EN560 304520-MM-870 for pure gases up to 5.0, with metal membrane SS321 (1.4541) external thread G3/8" RHk according to EN 560 304520-MM-6M ​​for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 6mm 304520-MM-8M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 8mm 304520-MM-10M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 10mm 304520-MM-12M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 12mm 304520-MM-15M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 15mm 304520-MM-18M for pure gases up to 5.0, with metal membrane SS321 (1.4541) compression fitting VA 18mm
