Vulkan L20 line pressure reducer for fuel gases G1/2RH, external on both sides
Standards & Design:

Single-stage design, with safety pressure gauges according to DIN EN ISO 5171
according to EN 560
according to EN 56
according to EN 560 104520-6M-6M for technical gases up to 4
according to EN 560 104520-MM-6M-6M for pure gases up to 5

Functional elements:

• safety pressure gauges according to DIN EN ISO 5171

Technical data:

• Maximum inlet pressure: 40 bar
• Output pressure: 0 - 20 bar
• Inlet pressure gauge: 0 - 60/40 bar
• Outlet pressure gauge: 0 - 40/20 bar

Performance:

• Maximum output: 70 Nm³/h
• at 20 bar outlet pressure

Connections:

• Inlet connection: external thread G1/2RHak according to EN 560
• Outlet connection: external thread G1/2RHak according to EN 560

Dimensions:

Width x Height x Depth: 200 x 200 x 75 mm

Variants & options:

• 104520 — for technical gases up to 4.5, with standard membrane on both sides. external thread G1/2" RHk(EN 560)
